D.T. Aspirator

Name: D.T. Aspirator
Brand: Rathore Agro Tech
Price: 140000 INR
Availability: InStock

Price 140000 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

D.T. Aspirator Specification

Usage
For Dust and Chaff Separation

Capacity
Up to 500 kg/h (Depends on Material)

Power
2 Horsepower (HP)

Accuracy
1%

Weight
Approx. 40 kg

Dimension (L*W*H)
600 x 400 x 900 mm

Air Compressor
Not Included

Application
iIndustrial

Type
D.T. Aspirator

Channels
Single & Multiple (Customizable)

Output
Continuous / Adjustable

Air Pressure
Standard Laboratory (Approx. 0.2-0.4 MPa)

Motor Speed
2800 RPM

Discharge Port
Adjustable Flow

Separation Principle
Air Suction via Blower

Operation
Automatic/Manual Switch

Material of Construction
Stainless Steel Body

Control Mode
Panel Controlled

Collection System
Detachable Hopper

Noise Level
Less than 75 dB

Mounting
Floor Standing

Voltage
220V/50Hz

D.T. Aspirator Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
7 Days

About D.T. Aspirator

The offered D.T. Aspirator is used as integral part of flour mill cleaning unit. With having standard production capacity, this electricity driven equipment has high operating speed and standard rated voltage. It is used to remove low-density particles from granular materials notably wheat. It can be combined with cleaners, destoner and scourers. Also, it is successfully used singly in flour mills, feed mills, seed cleaning plants, and oilseed cleaning plants. The offered D.T. Aspirator is made for efficient and long term use.

Efficient Dust and Chaff Separation

The D.T. Aspirator employs an air suction principle via a powerful blower, ensuring effective removal of dust and chaff from bulk materials. Its adjustable discharge flow and detachable hopper facilitate easy collection and management, making it ideal for a wide range of industrial applications where cleanliness and material purity are crucial.

Versatile and Customizable Operation

Designed for both continuous and adjustable output, this aspirator supports single or multiple channel configurations to suit specific processing needs. Operators can switch between manual and automatic modes using an intuitive panel, ensuring flexibility and efficient workflow in busy industrial environments.

Durable Construction with User-Friendly Features

Manufactured with a stainless steel body, the D.T. Aspirator is built for durability and hygiene while standing up to demanding daily use. Its floor-mounted design and compact dimensions (600 x 400 x 900 mm) provide stability and ease of installation in varied industrial settings. Panel-controlled operation ensures straightforward usage.

FAQ's of D.T. Aspirator:

Q: How does the D.T. Aspirator separate dust and chaff from materials?

A: The D.T. Aspirator uses air suction generated by a powerful blower, pulling airborne particles away from the bulk material as it passes through the unit. The process efficiently separates lighter dust and chaff, directing them into a detachable hopper for easy removal.

Q: What are the main benefits of using this aspirator in industrial settings?

A: Key advantages include precise dust and chaff separation (accuracy 1%), high processing capacity (up to 500 kg/h), durability thanks to stainless steel construction, and low noise operation (<75 dB). Adjustable flow and customizable channels support a variety of material types and throughput requirements.

Q: When is the D.T. Aspirator most effectively used?

A: The aspirator is particularly effective during material cleaning and processing stages where removal of dust or lightweight impurities is essential. It operates best in standard laboratory air pressure environments (0.2-0.4 MPa) and is suitable for both batch and continuous workflows.

Q: Where can the D.T. Aspirator be installed?

A: Its floor-standing design allows for quick installation in factories, processing plants, or laboratory environments. With its compact footprint (600 x 400 x 900 mm), the unit fits comfortably into various spaces without major modifications.

Q: What is involved in operating and maintaining the D.T. Aspirator?

A: The system can be controlled via a panel switch, allowing users to choose between automatic and manual modes based on workflow demands. Regular maintenance involves emptying the detachable hopper, ensuring the blower and channels remain clear, and periodic checks of the motor and controls for optimal performance.

Q: Can the D.T. Aspirator be used with different material types and volumes?

A: Yes, both single and multiple channel models can be customized to accommodate various materials. The aspirator's adjustable output supports a range of processing volumes up to 500 kg/h, depending on the material's nature and density.
